Datasheet: MAC3

The MAC3 float configuration from MAC3 is the most robust version. A round shape with smooth profile and extra strong construction which is best sewage and other fouling applications. The PVC cable is suitable for general water applications. The PVC cable is not for use with chemicals or in application with fats, oils and/or grease. Use the version with Neoprene cable if oils, fats and/or grease is present.

Stocked in a 3 wire configuration (change over contact), suitable for filling and emptying applications. Stocked with cable lengths of 1m, 3m, 5m, 10m, 15m, 20m, 30m and 50m. Other lengths can be available under special order.

To order a configuration not included in the above list or request a quotation, send your request to: sales@birkettcontrols.com.au

or Contact us for more information on 0432 114 574 or 02 9319 1808

MAC3 PVC

The minimum working distance between the MAC3 level regulator and the fixing point is 20 cm. The optional counterweight can be purchased to eliminate the need for fixing the cable inside the tank or pit.

Application Areas:

Sewage and waste pit pump control. Also commonly used in drainage and storm water pits.

Technical Specifications:

10(4)A, 250 Vac, Class II.

see data sheet via the above link for more information
