Panasonic AFP7CCM1 | FP7 Add-on cassettes
Spec Detail
| Item | Specifications |
|---|---|
| Product Number | AFP7CCM1 |
| Part Number | AFP7CCM1 |
SPECIFICATIONS
| Item | Specifications |
|---|---|
| Interface | RS-422 / RS-485 1 channel |
| Transmission distance | Max. 1,200 m 3,937 ft at RS-485 mode, Max. 400 m 1,312 ft at RS-422 mode (Note) If mixed C-NET adapters are used, up to 32 units can be connected, but transmission speed will be limited to a maximum of 19.2 kbits/sec. |
| Transmission speed | 300,600,1200,2400,4800,9600,19200,38400,57600,115200, 230400 bits/sec. |
| Communication method | Half-duplex system |
| Synchronous method | Start-stop synchronization system |
| Transmission format | Stop bit: 1 bit / 2 bits Parity: Invalid / Valid (Odd / Even) Data length: 7 bits / 8 bits Start code: with STX / without STX End code: CR / CR + LF / None / ETX |
| Data transmission order | Transmit from bit 0 in character units. |
| Number of connected units | For general-purpose communication: Max. 99 units For computer link: Max. 99 units For PLC link: Max. 16 units For MODBUS-RTU: Max. 99 units (Note) If mixed C-NET adapters are used, up to 32 units can be connected, but transmission speed will be limited to a maximum of 19.2 kbits/sec. (Note) The converter SI-35 manufactured by LINE EYE Co., Ltd. is recommendable for the RS-485 at the computer side. When you use the SI-35, please adjust time after FP7 series PLC receives a command until it returns a response by a program. (Note) 1: 1 for RS-422 interface. |
COMMON GENERAL SPECIFICATIONS
| Item | Specifications |
|---|---|
| Ambient temperature | 0 to +55 degrees +32 to +131 degrees Fahrenheit , at storage: -40 to +70 degrees -40 to +158 degrees Fahrenheit |
| Ambient humidity | 10 to 95 % RH (at 25 degrees 77 degrees Fahrenheit , no condensation), at storage: 10 to 95 % RH (at 25 degrees 77 degrees Fahrenheit , no condensation) |
| Breakdown voltage | 500 V AC for 1 minute |
| Insulation resistance | 100 MOhm or more (at 500 V DC) |
| Vibration resistance | 5 to 8.4 Hz, single amplitude of 3.5 mm 0.14 in, 1 sweep/min. (IEC61131-2); 8.4 to 150 Hz, constant acceleration of 9.8 m/s2, 1 sweep/min. (IEC61131-2); for 10 min. each in X, Y, and Z directions |
| Shock resistance | 147 m/s2 or more, 3 times each in X, Y, and Z directions (IEC61131-2) |
| Noise immunity | 1,000 V [p-p] with pulse width 50 ns and 1 micro s (using a noise simulator) |
| Operating condition | Free from corrosive gasses and excessive dust |
INDIVIDUAL GENERAL SPECIFICATIONS
| Item | Specifications |
|---|---|
| Rated voltage range | - |
| Current consumption | 60 mA or less (Note) Increased CPU unit current consumption |
| Net weight | 25 g approx. (with terminal block) |
